High pressure micro powder mill

1. Larger application range compared with pneumatic mill.
2. 800-1200Kg of pressure enhancement by the high pressure spring compared with other mills.
3. Energy saving, only one third of energy consumption compared with pneumatic mill.
4. Small in investment and high in profit. Only one eighth of price compared with pneumatic mill.
5. Big feeding size and small discharging size (average one-off size is 6.5um).

Inquiry Us

On basis of many times of experiments and improvement and introducing the latest mechanical techniques of Sweden, high pressure micropowder grinding mill, the latest industrial micro-powder grinding mill, is a new type grinding machine for producing micro-powder.

High pressure micro-powder grinding mill can grind calcite, limestone, calcite, dolomite, kaolin, bentonite, talc, illite, pyrophillite, barite, meerschaum, fluorite, potash ore and other more than 200 kinds of materials that Moh's hardness is below 6, non-explosive, non-flammable minerals.

Unique Advantages of High Pressure Micro Powder Mill

1. Small in investment and high in profit. Only one eighth of price compared with pneumatic mill.

2. Larger application range compared with pneumatic mill.

3. 800-1200Kg of pressure enhancement by the high pressure spring compared with other mills.

4. Energy saving, only one third of energy consumption compared with pneumatic mill.

5. The de-dusting effect is fully comply with national standard.

6. Big feeding size and small discharging size (average one-off size is 6.5um).

7. High airproof ability with multi-grade sealing device.

Technical Data

Type Parameter	Micropowder93	Micropowder92	Micropowder87	Micropowder76	Micropowder66
Feeding size （mm）	≤25	≤25	≤20	≤20	≤15
Size of finished product （mm）	0.125-0.010	0.125-0.033	0.125-0.010	0.125-0.033	0.125-0.010
Shift output of different material fineness（t)	0.8-12	0.6-10	0.4-8	0.3-6	0.2-4
Rotate speed of central shaft （r/min）	140	148	160	170	180
Diameter of pulverizing ring （mm）	1006	973	907.5	850	725
Diameter of pulverizing roller （mm）	300	300	270	260	210
Height of pulverizing roller （mm）	160	160	150	150	150
Main motor	Y225M-8-30	Y225M-8-30	Y225M-8-22	Y225S-8-18.5	Y225M-8-15
Fan motor	Y160E-2-22	Y160L-4-22	Y160L-4-18.5	Y160L-4-15	Y160L-4-11
Analyzer motor	YCT180M-4A-4	YCT180M-4A-4	YCT180M-4A-4	YCT160-4B-3	YCT160-4B-3
