Conveyor belt
Belt width:500 - 1600/mm
Power:3 - 15/kw
Conveying length:≤10 - ≤12/m
Conveying speed:1.3-1.6 to 1.3-2.0m/s
Conveying capacity:78-191 to 1069-2195t/h
Supply Ability:35 Set/Sets per Month
Feature:Easy to use
Belt width:500 - 1600/mm
Power:3 - 15/kw
Conveying length:≤10 - ≤12/m
Conveying speed:1.3-1.6 to 1.3-2.0m/s
Conveying capacity:78-191 to 1069-2195t/h
Supply Ability:35 Set/Sets per Month
Feature:Easy to use
The belt conveyor is the commonly used transportation equipment in the daily production process. The quality of belt conveyor depends on its hot and cold resistance property and stability which are decided by the day-to-day work environment. The belt conveyor is the hub of the entire production line. If it fails, the entire production line will be forced to stop.
In order to ensure the regular operation of belt conveyor, the operator should observe at any time and eliminate the failures timely. For the cost of belt conveyor constitutes a considerable part of the entire conveyor system, we must pay attention to training the operator and repairman and providing professional operation and maintenance knowledge to reduce the costs of replacement and maintenance.
Hongxing belt conveyor has high quality and efficiency. Our customers have spread over all fields such as mining, electricity, chemical, steel, cement, building material and printing. Improving the efficiency and reducing the cost are our enduring mission. Adhering to the "roots in the value-added services" and "products customer’s favorite products", Hongxing will serve all the clients with the best quality products and service.
Belt width (mm)
|
Conveying length(m)
Power(kw)
|
Conveying speed (m/s) | Conveying capacity(t/h) | ||
500 |
≤12
----- 3 |
12-20
----- 4-5.5 |
20-30
----- 5.5-7.5 |
1.3-1.6 | 78-191 |
650 |
≤12
----- 4 |
12-20
----- 5.5 |
20-30
----- 7.5-11 |
1.3-1.6 | 131-323 |
800 |
≤6
----- 4 |
6-15
----- 5.5 |
15-30
----- 7.5-15 |
1.3-1.6 | 278-546 |
1000 |
≤10
----- 5.5 |
10-20
----- 7.5-11 |
20-40
----- 11-22 |
1.3-2.0 | 435-853 |
1200 |
≤10
----- 7.5 |
10-20
----- 11 |
20-40
----- 15-30 |
1.3-2.0 | 655-1284 |
1400 |
≤10
----- 11 |
<10-20
----- 18.5 |
<20-40
----- 22-37 |
1.3-2.0 | 893-1745 |
1600 |
≤10
----- 15 |
<10-20
----- 22 |
<20-40
----- 30-45 |
1.3-2.0 | 1069-2195 |
